Lamello -CLAMEX P14 Flexus

The Clamex P-14 Flexus is another of the P-System based series of demountable joints and is connected by a swivel latch. Clamex P-14 Flexus therefore offers all the existing advantages of the P-System.

These include quick tool-free installation, lateral tolerances, torsion prevention and stackability. What differentiates the Clamex P-14 Flexus from the Clamex P-14 are the flexible positioning pins.

Thanks to the flexible positioning pins, no rigid connector elements protrude. This new feature enables the subsequent installation of workpieces into existing components and therefore greatly simplifies the assembly process.

Positioning pins serve as positioning and fixing elements for workpieces. Therefore, the fixed shelves remain in place while the workpieces are tightened with the hexagonal wrench.

The double-sided bevel of the positioning pins allows the workpiece to be disconnected again. The positioning pins are easily inserted into the counter-beam, allowing for seamless installation of elements with 90° angles.

• Material: glass fibre reinforced plastic Dimensions: 64 x 13.5 x 9.7 mm
• 52 x 7.5 x 9.7 mm
• Mounting tolerance: longitudinal ± 0 mm
• radially ± 1 mm
• Scope of delivery: 1x pair
• Applicable in materials with a minimum thickness of 18/16/12 mm depending on the type of joint
